i-tec USB 3.0 Metal HUB 3 Port + Gigabit Ethernet Adapter, 10/100/1000 Mbps, USB 3.0 to RJ-45, Notebook Ultrabook Tablet, Windows Mac Linux

P/N:
U3GLAN3HUB
EAN:
8595611700866




METAL Series is the latest i-tec product line in a stylish elegant metal design and exclusive package.

i-tec USB 3.0 Metal HUB 3 Port with Gigabit Ethernet Adapter combines the functions of 3-port USB 3.0 HUB with Gigabit Ethernet adapter.
It offers three USB 3.0 ports with Plug & Play option. The USB 3.0 interface is important mainly for data transfers from USB 3.0 memory cards and flash disks which will use its high transfer speed most. HUB is powered from the USB bus and has a built-in surge protection for your computer in the event of a short circuit on the peripheral devices. The interface is backward compatible with USB 2.0. You will just connect the HUB by the USB cable to your computer and immediately you can start using it. It is an ideal companion for everybody who does not have enough USB ports in his/her notebook, ultrabook or PC and who has to constantly connect and disconnect his/her favorite USB equipment such as flash disks, mobile phones, tablets, digital cameras, MP3 players, printers, etc.
The Gigabit Ethernet port allows user's computer instantly connect to a 10/100/1000Mbps network. No need to purchase an extra Gigabit network card and share a PCI or Cardbus slot. With compliance with USB 3.0 specification, this adapter ensures true 10/100/1000Mbps network speed without any compromise.
Ethernet network connection can also be used in the Android system. However, the support of this function must be included by the manufacturer directly in the particular Android device. You can easily check this support in Network Connection Settings → Other Networks, which must include Ethernet.
Besides, compact and bus-powered design means external power is not required.

In case of problems with the installation, technical difficulties or incorrect function of the equipment, check first for the possible solution in the FAQ tab.

Note: For Mac OS X Yosemite is necessary to install drivers from our website (bookmark download).




  • 3x USB 3.0 port Type-A for connecting USB equipment
  • 1x USB connector Type-A for connecting to a notebook / PC
  • 1x Ethernet 10/100/1000Mb/s LAN RJ-45 port with function MDI/MDIX and self-correction
  • VIA VL812 chipset compliant with USB 3.0 specification, revision 1.0
  • Realtek RTL8153 USB 3.0 to Gigabit Ethernet Adapter chipset – supports standard IEEE 802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3az (Energy Efficient Ethernet); support Jumbo frame up to 9kB
  • Interface USB 3.0, backward compatible with USB 2.0
  • LED indication for charging status and Ethernet connection
  • Supports Wake-on-LAN
  • Product dimensions 110 x 35 x 23 mm
  • Product weight 73 g
  • Packaging dimensions 180 x 105 x 50 mm
  • Packaging weight 140 g


SYSTEM REQUIREMENTS
Hardware requirements: notebook / PC with free USB 3.0 / 2.0 port. If you connect to USB 2.0 transfer speed and some function can be limited. CPU Processor Intel Pentium 1.2GHz and higher, 512MB RAM.

Operation system: Windows XP SP3 / Vista / 7 / 8 / 8.1 / 10 32/64 bit, Mac OS X, Linux, Android

PACKAGE CONTENTS

  • i-tec USB 3.0 Metal HUB 3 Port with Gigabit Ethernet Adapter with built-in cable (20 cm)
  • CD (Driver and User's manual)
  • Quick Installation Guide



General problems with USB 3.0 - please click here.

Question: I would like to charge Apple device (iPad, iPhone, iPod) in OS Windows over the USB 3.0 / 2.0 port. Is there any software option to solve this problem?
Answer: Standard charging is solved via the supplied AC adapter for Apple device. Nevertheless, by ASUS company was developed the „ASUS Ai Charger“ software for working and simultaneously charging of Apple device over the USB port of notebook / PC, over the plugged HUB or docking station in Windows OS. More information can be found here: http://event.asus.com/mb/2010/ai_charger/, where you can download and test the software. In spite of many positive experiences with the using of this software, we cannot guarantee 100% effectivity in all possible hardware combinations.

Question: Device disconnected or doesn´t work properly in Mac OS X Yosemite.
Answer: For Mac OS X Yosemite is necessary to install drivers from our website. Previous versions of Mac OS have drivers incorporated.

Question: My computer cannot detect the device, or the HUBs function is limited.
Answer: Check drivers of USB 3.0 interface on your computer. These drivers must be up-to-date. For further information check our website (section USB 3.0 PROBLEMS)

Question: Can I obtain more detailed information about problems with the device?
Answer: Of course, you can contact our technical support.

Question: LAN does not work correctly.
Answer: Check all cables between the notebook / PC and the active element of your network and push the USB and RJ-45 connectors.
